Model Whirlpool 676AM-KLSVW GAS RANGE – Common Parts & Diagrams
02 - DOOR/DRAWER
01 - CONTROL PANEL/TOP ASSY./BODY
03 - OVEN
Common parts from model Whirlpool 676AM-KLSVW GAS RANGE
1
GLASS, DOOR INNER WPL 7902P03560 Contact Us For Availability
1
BACK, MAIN WPL 4002F16580 Contact Us For Availability
1
BACK, BROIL WPL 4002F12345 Contact Us For Availability
1
COVER, BKGD BROIL SECTION WPL 4005F27945 Contact Us For Availability
2
BAFFLE, OVEN DOOR WPL 3601F09451 Contact Us For Availability
2
BOX, BURNER WPL 4011F19680 Contact Us For Availability
2
BAFFLE, OVN FRONT WPL 3601W12416 Contact Us For Availability
2
SCREW W/WASHER WPL 7101P12460 Contact Us For Availability
3
CLIP, DOOR WPL 7112P03460 Contact Us For Availability
3
BOX, FLUE WPL 4006W02680 Contact Us For Availability
3
BOTTOM, BROILER WPL 4011F16180 Contact Us For Availability
4
FRAME, DOOR WPL 7706P24360 Contact Us For Availability
4
BRACKET,CONTROL PANEL (R) WPL 3801F04734 Contact Us For Availability
4
BRACKET,CONTROL PANEL (L) WPL 3801F04934 Contact Us For Availability
4
BOTTOM, OVEN WPL W10116822 Contact Us For Availability
5
SCREW WPL 7101P30560 Contact Us For Availability
5
CLIP, HINGE PIN WPL 7112P01960 Contact Us For Availability
5
COVER WPL 4005F08880 Contact Us For Availability
5
RECEPTACLE, LAMP WPL 7408P00260 Contact Us For Availability
6
GLASS, DOOR WPL 7902P27560 Contact Us For Availability
6
CLIP, TOP RETAINER WPL 7112P07360 Contact Us For Availability
6
FRAME, LOWER OVEN WPL 2201F07419 Contact Us For Availability
7
HANDLE, DOOR WPL 7701P04760 Contact Us For Availability
7
FRONT, BURNER BOX WPL 4012F02180 Contact Us For Availability
7
SCREW (1/2``) WPL 7101P04060 Contact Us For Availability
7
NOT REQUIRED PART OR SEE NOTE WPL W10124350 Contact Us For Availability
8
SCREW, HANDLE WPL 7101P28360 Contact Us For Availability
8
HANDLE, DRAWER (CHR) WPL 7701P01260 Contact Us For Availability
8
HINGE ASSY. (LT) WPL 3418A02934 Contact Us For Availability
8
HINGE ASSY. (RT) WPL 3418A03034 Contact Us For Availability
8
GLIDE, OVEN DOOR HINGE WPL 8016P00860 Contact Us For Availability
8
SEAL WPL 7212P00160 Contact Us For Availability
9
FRAME, WINDOW----NA WPL 3603F01380 Contact Us For Availability
9
KNOB, THERMOSTAT WPL 7731P01860 Contact Us For Availability
9
HOUSING, LAMP WPL 4001F01619 Contact Us For Availability
10
LINING, OVEN DOOR WPL 2402W15416 Contact Us For Availability
10
KNOB, VALVE WPL 7733P06560 Contact Us For Availability
10
BULB, OVEN WPL 7407P02660 Contact Us For Availability
11
INSULATION, DOOR WPL 4804F02160 Contact Us For Availability
11
LINING, INNER SIDE WPL 4009W07880 Contact Us For Availability
11
NUT, NYLON WPL 7103P04560 Contact Us For Availability
11
GROMMET, NYLON WPL 8008P01260 Contact Us For Availability
11
LINING, BROILER SIDE WPL 4009F04545 Contact Us For Availability
12
PANEL, DRAWER (WHT) WPL 2416F02571 Contact Us For Availability
12
PANEL, DRAWER (ALM) WPL 2416F02574 Contact Us For Availability
12
CLIP, TOP RETAINER WPL 7112P04260 Contact Us For Availability
12
SCREW WPL 7118P00460 Contact Us For Availability
12
CONTROL PANEL WPL Y7712P14360 Contact Us For Availability
12
PAN, BROIL WPL 3401F00419 Contact Us For Availability
13
SCREW, FRAME WPL 7101P12660 Contact Us For Availability
13
PANEL, SIDE (BLACK) WPL 2618F07370 Contact Us For Availability
13
PANEL, SIDE (WHT)----NA WPL 2618F07371 Contact Us For Availability
13
PANEL, SIDE (ALM) WPL 2618F07374 Contact Us For Availability
13
RACK, OVEN WPL 7801P03060 Contact Us For Availability
14
PIN, HINGE WPL 7113P00260 Contact Us For Availability
14
SUPPORT, OVEN REAR WPL 3807F20545 Contact Us For Availability
15
SCREW WPL 7101P06160 Contact Us For Availability
15
SEAL, RUBBER WPL 7208P01160 Contact Us For Availability
15
SCREW WPL 7101P11260 Contact Us For Availability
15
TRACK, BROILER DWR RIGHT WPL 3404A01351 Contact Us For Availability
15
TRACK, BROILER DWR LEFT WPL 3404A01451 Contact Us For Availability
15
SCREW WPL 7101P11560 Contact Us For Availability
16
BROILER DRAWER ASSY. WPL 3407W00919 Contact Us For Availability
16
SCREW WPL 7101P07660 Contact Us For Availability
16
LOCK NUT, CATCH WPL 7103P06760 Contact Us For Availability
16
LEG, LEVELING WPL Y7101P25460 Contact Us For Availability
16
BRACKET WPL 3801F02145 Contact Us For Availability
16
COVER, DISCONNECT WPL 4005F27745 Contact Us For Availability
17
INSULATION WPL 7002P00260 Contact Us For Availability
17
SUPPORT, MAIN TOP WPL 3807F43145 Contact Us For Availability
17
CLIP, THERMOSTAT WPL 7112P00460 Contact Us For Availability
18
SPACER, GLASS CORNER WPL 8010P04560 Contact Us For Availability
18
GRATE (BLK) WPL 2003W02300 Contact Us For Availability
18
INSERT, BROIL PAN WPL 3413F00219 Contact Us For Availability
19
LINING, BROILER DRAWER WPL 2404F02119 Contact Us For Availability
19
SCREW WPL 7101P05860 Contact Us For Availability
19
BRACKET, ANTI-TIP WPL 3801F21851 Contact Us For Availability
19
SCREW, BRACKET WPL 7101P28960 Contact Us For Availability
19
CORD, POWER WPL 7402P02460 Contact Us For Availability
19
BUSHING, SNAP WPL 8007P00360 Contact Us For Availability
20
HINGE, BROILER (LT) WPL 3418A06334 Contact Us For Availability
20
SPACER, MAIN TOP WPL 8003P01160 Contact Us For Availability
21
HINGE, BROILER (RT) WPL 3418A06234 Contact Us For Availability
21
SPRING, OVEN DOOR WPL 7803P05860 Contact Us For Availability
22
CATCH WPL 8002P00160 Contact Us For Availability
22
STOP, OVEN DOOR WPL 3420A03334 Contact Us For Availability
23
LINK, BROILER WPL 7807P00160 Contact Us For Availability
24
SPRING WPL 7803P01460 Contact Us For Availability
24
TOP, MAIN WPL 2001F08081 Contact Us For Availability
24
TOP, MAIN WPL 2001F08084 Contact Us For Availability
24
HARNESS SUPPLY WPL 5120A00860 Contact Us For Availability
24
HARNESS, LOWER WPL 5185D25360 Contact Us For Availability
25
SCREW WPL 7101P11460 Contact Us For Availability
26
INSERT, HANDLE (CHROME) WPL 7728P06860 Contact Us For Availability
× ![]()
