Model Electrolux 253.19501992 Freezer (Kenmore 25319501992) – Common Parts & Diagrams

1
Frigidaire Freezer Lid Gasket (White)
Frigidaire Freezer Lid Gasket (White) WCI 216480801 Contact Us For Availability
View on Model
1
Freezer Condenser Coil
Freezer Condenser Coil WCI 5300120779 Contact Us For Availability
View on Model
5
Harness W/po
Harness W/po WCI 216552000 Contact Us For Availability
View on Model
9
Freezer Door Inner Liner Screw
Freezer Door Inner Liner Screw WCI 216061502 Contact Us For Availability
View on Model
10
Plug Button (White)
Plug Button (White) WCI 216141101 Contact Us For Availability
View on Model
11
Kelvinator Freezer Lid Outer Panel (White)
Kelvinator Freezer Lid Outer Panel (White) WCI 216106014 Contact Us For Availability
View on Model
22
Clip
Clip WCI 216056400 Contact Us For Availability
View on Model
28
Hinge Assembly
Hinge Assembly WCI 216478800 Contact Us For Availability
View on Model
28
Support
Support WCI 5303212615 Contact Us For Availability
View on Model
30
Freezer Corner Trim
Freezer Corner Trim WCI 216105500 Contact Us For Availability
View on Model
30
PTC Starter
PTC Starter WCI 216511200 Contact Us For Availability
View on Model
31
Overload Protector
Overload Protector WCI 216100113 Contact Us For Availability
View on Model
42
Washer
Washer WCI 216232700 Contact Us For Availability
View on Model
53
Cover
Cover WCI 216347800 Contact Us For Availability
View on Model
75
Access Panel
Access Panel WCI 216329402 Contact Us For Availability
View on Model
85
Wire
Wire WCI 216533100 Contact Us For Availability
View on Model
86
Screw Rwh #8
Screw Rwh #8 WCI 216707700 Contact Us For Availability
View on Model
NI
Service Data Sheet
Service Data Sheet WCI 216654900 Contact Us For Availability
View on Model
NI
Owner's Manual
Owner's Manual WCI 216775500 Contact Us For Availability
View on Model
NI
Parts Catalog
Parts Catalog WCI 5995346250 Contact Us For Availability
View on Model
